LixelSky K1 Surveying Equipment Scanner Cheap Price Hanhheld 3D Scanner Navigation LiDAR Waterproof Laser Scanner
Product Introduction
The xgrids LixelSky K1 is a highly acclaimed compact handheld 3D scanning and modeling device. Here is a detailed evaluation of it:
I. Performance Characteristics
1.High-precision Real-time Modeling:
1.The xgrids LixelSky K1 integrates high-performance vision, laser, and inertial navigation modules, capable of generating color 3D models in real-time with centimeter-level accuracy.
2.The laser radar scans at a speed of 200,000 points per second, with an accuracy of ±1.2cm and a measurement range of up to 40m, ensuring the accuracy and completeness of scan data.
2.Portable and Easy to Use:
1.The xgrids LixelSky K1 weighs less than 1kg and has a compact size, making it easy to carry and operate.
2.The device supports one-click start and automatic calibration, reducing the difficulty of use and allowing non-professionals to easily get started.
3.Multi-source Data Fusion:
1.The xgrids LixelSky K1 can fuse multiple data sources such as laser, vision, and GNSS for SLAM calculation, improving the stability and scene adaptability of scanning.
2.This multi-source data fusion technology enables the device to obtain high-quality 3D models even in complex environments.
4.Diverse Application Scenarios:
1.The xgrids LixelSky K1 is suitable for various application scenarios, such as cultural relic preservation, scenic area mapping, and forestry surveys.
2.Its high precision and portability allow the device to excel in these scenarios.
II. User Evaluation
Based on user feedback, the xgrids LixelSky K1 has received widespread praise. Users generally believe that the device is easy to operate, has high modeling accuracy, and a wide range of applications. At the same time, the device's compactness and portability have also been appreciated by users, allowing them to easily carry and use it during outdoor work or long-distance travel.
III. Price and Cost-effectiveness
The price of the xgrids LixelSky K1 is relatively reasonable. Considering its high precision, portability, and multi-source data fusion features, its cost-effectiveness is very high. For users who need to frequently perform 3D scanning and modeling, the xgrids LixelSky K1 is undoubtedly a worthwhile consideration.
IV. Summary
In summary, the xgrids LixelSky K1 is a 3D scanning and modeling device with excellent performance, portability, ease of use, wide application scenarios, and high cost-effectiveness. Whether you are a professional surveying and mapping personnel or a 3D enthusiast, you can benefit greatly from this device. If you are looking for a high-quality 3D scanning and modeling device, then the xgrids LixelSky K1 is undoubtedly a recommended choice.
Logistics information
Logistics information
Technical Specifications
The parameters of the xgrids LixelSky K1 handheld scanner are as follows:
I. Basic Parameters
|
Brand |
xgrids |
|
Model |
LixelSky K1 |
|
Color |
Silver |
|
Weight |
Approximately 760g |
|
Shell Material |
Aviation aluminum |
|
Operating Temperature |
-20°C to 50°C |
|
Power |
<20W |
|
Display Method |
LCD display |
|
Power Input |
14.4V |
|
Internal Storage |
256G TF card |
|
Total Operating Time |
1.5 hours |
|
Data Interface |
USB 3.1 Gen2 |
|
Protection Level |
IP54 |
II. Scanning and Modeling Parameters
|
Number of Cameras |
4 |
|
Panoramic Cameras |
48MP × 2, supporting 360° × 360° true panoramic shooting |
|
LiDAR |
Scanning speed of 200,000 points/second, accuracy of ±1.2cm, measurement distance of 40m, horizontal field of view of 360° |
|
Measurement Accuracy |
1.2cm |
|
Operation Method |
Program control |
III. Other Parameters
|
Application Scenarios |
Suitable for cultural relic preservation, scenic area mapping, forestry surveys, indoor virtual decoration design, and other various scenarios |
|
Customization Service |
Does not support processing customization |
|
Country of Origin |
China |
In summary, the xgrids LixelSky K1 handheld scanner is a high-performance, high-precision 3D scanning and modeling device, featuring portability, ease of use, and multi-source data fusion, suitable for various application scenarios. For more information, please contact our customer service department.
