JOUAVCW-25E long-duration electric fixed-wing vertical take-off and landing unmanned aerial vehicle

JOUAV CW-25E UAV is the 1 fixed-wing UAV with excellent performance and comprehensive functions. The following is a detailed evaluation of it:

Long endurance: CW-25E UAVs have a long endurance time, depending on the payload, the endurance time can reach 180 to 240 minutes to meet the needs of long-term missions.

High speed: the cruising speed reaches 72 km/h, which can quickly cover a large area and improve the operation efficiency.

High load: The payload capacity is up to 6.6kg, which can carry a variety of mission payloads, such as aerial cameras, radars, photoelectric pods, etc., to meet the needs of diverse missions.

High lift limit: the practical lift limit reaches 6500m, the highest take-off altitude is 4000m, suitable for various complex flight environments.

Vertical take-off and landing: pure electric vertical take-off and landing design, no runway, flexible and convenient take-off and landing.

One-key takeoff and landing: No radio control, support one-key takeoff and landing, easy to operate and safe.

High-precision navigation: It integrates high-precision MEMS inertial sensors, high-performance CPU and dual GPS positioning system to provide precise navigation and positioning services, with strong anti-EMI and anti-seismic capabilities.

Advanced flight control: equipped with dual GPS and dual compass, advanced flight control and navigation system, GPS or data link timeout will automatically return to ensure flight safety.

Multiple payload support: supports multiple smart payloads, such as aerial cameras and radars, and is suitable for different application scenarios.

Complete supporting software: Provide a one-stop drone product, including supporting software required for missions, which can be used to plan flight paths, control and manage drones, track and identify targets, and view drone video and geographic data information in real time.

High applicability: Equipped with self-heating pitot tube, it can fly in harsh environments such as high altitude, high humidity, low temperature, light rain, etc., to improve the applicability of UAVs.

Strict testing: After rigorous testing and verification, to ensure the safety and stability of the UAV.

Data security: Provides hard data encryption to ensure the security of information transmission and storage.

Modular design: easy to maintain and upgrade, reduce the cost of use.

Professional after-sales support: Provide perfect after-sales service and technical support to ensure that users get timely help during use.

To sum up, JOUAV CW-25E UAV has become the 1 highly respected industrial UAV product with its excellent performance, advanced technology, comprehensive functions, safe and reliable performance and convenient operation. Whether it is used in surveying and mapping geographic information, inspection, security monitoring or emergency response and other fields, CW-25E have shown a strong strength and a wide range of application prospects.

The detailed parameters of JOUAV CW-25E UAV are as follows:

Type: Pure electric fixed-wing UAV with vertical take-off and landing capability

Body length: 2.08 meters

Wingspan: 4.35 meters

Maximum takeoff weight: 31.58kg

Endurance: 180 to 240 minutes depending on the payload

Cruising speed: 72 km/h

Service ceiling: 6500m (6000m, may vary depending on version or configuration)

Maximum take-off altitude: 4000m

Wind resistance: 7 wind

Landing accuracy: less than 15cm

Payload capacity: 6.6kg

Load options: aerial camera, radar, photoelectric pod, aeromagnetic, spectral sensors and other options

Navigation system: integrated high-precision MEMS inertial sensor, high-performance CPU, dual GPS positioning system, strong anti-EMI and seismic capability

Flight Control & Navigation: Dual GPS and Dual Compasses, Advanced Flight Control and Navigation System, Automatic GPS or Data Link Timeout Return

Self-heating pitot tube: can fly in high altitude, high humidity, low temperature, light rain and other harsh environments

Portability: equipped with portable ground station, portable battery, flight link antenna, etc., easy to carry and deploy

Software support: Provide a one-stop drone product, including mission-related software, which can be used to plan flight paths, control and manage drones, track and identify targets, and view drone video and geographic data information in real time

In summary, with its excellent performance parameters and comprehensive functional characteristics, JOUAV CW-25E UAV has a wide range of applications in surveying and mapping geographic information, inspection, security monitoring and other fields. Whether it is long time, high speed, high load or high lift limit, CW-25E have shown a strong strength.
